Product Description

Introduction

Venlo polycarbonate sheet greenhouse uses single layer or multi-layer hollow polycarbonate sheet as the top and surrounding enclosure with special aluminum alloy profile frame. The greenhouse framework uses hot dip galvanized steel, with beautiful appearance, high light transmittance good thermal insulation performance. The special anti-UV polycarbonate sheet can ensure the light transmittance and good thermal insulation performance.

The polycarbonate sheet has characteristics of light weight, good day lighting, great thermal insulation performance, anti-UV, dew-free, hail proof, high flame retardant, anti aging and etc.

Specification	Details
Cover Material	Hollow polycarbonate sheet (4mm / 6mm / 8mm)
Structure Material	Hot-dip galvanized steel
Span Width	8m / 9.6m / 10.8m / 12m
Bay Length	4m / 5m
Gutter Height	3m / 4m / 4.5m (customizable)
Top Height	4.8m – 6.5m
Snow Load	0.5–1.0 kN/m²
Wind Load	≥100 km/h
Light Transmission	80–85%
Lifespan	PC sheet: 10+ years; structure: 15–20 years

Polycarbonate sheet

6-10mm Polycarbonate sheet
High shock resistance
Anti-drip, Anti UV
Light transmittance>88%
Colour: white
Service life: over 10 years

Main structure

The main structure is made of hot-dip galvanized pipes and connected by hot-dip galvanized bolts, featuring excellent anti-corrosion performance and a service life of over 20 years.

Covering material

The top cover is made of polycarbonate hollow board with an outer layer of UV protection and an inner layer of anti-condensation. The four walls are made of polycarbonate hollow board or glass as per the conventional requirements. Depending on the differences in regional climate conditions, in some cold regions, the walls can be made of insulation composite boards. Sliding Windows can also be installed to increase the ventilation area of the greenhouse.

Main configuration

The greenhouse can be fully automatically controlled and equipped with facilities such as internal and external shading, skylights and side Windows for ventilation, wet curtains and fans for cooling.

Multi-span Hydroponic Agricultural PC Sheet Greenhouse

Name: Multi-span Hydroponic Agricultural PC Sheet Greenhouse - STARFARM
Brand: STARFARM
Price: 20.00 CNY
Availability: InStock

If you need customized products, Contact Us !

Category PC Board Greenhouse

Multi-span Hydroponic Agricultural PC Sheet Greenhouse

If you need customized products, Contact Us !

Category PC Board Greenhouse

Product Description

Related products

Easy Install Multi Span External Shading Agricultural Greenhouse

Large Agricultural Greenhouses With PC Sheet

Polycarbonate Sheet High Transparency Agricultural Farming Greenhouse

Professional-Grade Modular PC Panel Greenhouse

Custom Venlo Polycarbonate Plant Greenhouse

PC Green House Hot-dip Galvanized Steel Frame Greenhouse Kit

Size:Large
Type:Multi-Span Agricultural Greenhouses
Place of Origin:Jiangsu, China
Manufacturer:Starfarm
Cover Material:Pc Sheet
Model Number:GH-MS-P-2501
Brand Name:Starfarm
Product name:Venlo polycarbonate sheet greenhouse
Application:Vegetable Fruits Flowers Growth
Usage:Flower Vegetable Growing
Material:Hollow polycarbonate sheet+Hot-dip galvanized steel
Features:Stable Structure Easily Assembled
Color:Transparent/White
Length:4m / 5m Customized
Covering:Hollow polycarbonate sheet
Structure:Hot Dip Galvanized Steel Structure
Advantage:Low Cost High Output
