Descripción del producto

H5fe00a58af224b539c0429353a09099aK
Hd3be96e5dbac4999b3adf7bb9ebf46c25

Introducción

The design concept of the greenhouse is to “adhere to the principles of science and practicality;” Adhere to the principles of improving the utilization rate of land resources, energy conservation, water conservation and high efficiency. Adhere to the principle of choosing advanced, reliable and applicable materials and equipment for greenhouse structures. Therefore, in accordance with the construction requirements, we select the best imported or domestic products for the key parts of each system.


Besides nice appearance ,glass greenhouse has high light transmittance over 90%, provides good anti – corrosion and fire resistance performance strong ability of resisting wind and snow .
We can also design according to different area climate.
Item
Detalles
Structure Type
Venlo Type Steel Frame
Material de cubierta
4–5mm Single / 6–8mm Double Tempered Glass
Ancho de vano
6m, 8m, 9.6m, 10.8m, 12m
Bay Spacing
4m – 6m
Ridge Height
4.5 – 6.5 m
Length
30 – 100+ m
Wind load
0.6KN/m
Snow load
0.5KN/m
Dead load
18kg/m
Rainwater drain capacity
140mm/h at maximum
Drainage System
Integrated PVC Gutter
Ventilation System
Manual or Automated Roof & Side Vents

Glass

Tempered glass / 5+6+5mm hollow glass

High shock resistance / Anti-drip, Anti UV / Light transmittance>90%
Color: white

Service life:over 25 years

Other option: diffuse glass

Cover material

5mm tempered glass on roof ,5+6+5mm double layer glass at sides . All glasses are installed with aluminum alloy frame , sealed by EPDM rubber strip .

Structure

Venlo type hot-dip galvanized steel structure , good anti-corrosion ability,service life over 20years.

Other devices

External and internal shading system , roof and side windows , cooling system , fully automatically controlled in one greenhouse control system
He8ff26facf68474495d8efbc1f8a15a72
Hae381b209bba4550ae36a01c58247622H
Hdf9e78272d984711871bd8deca4e7a0bj
Hf5126190cfa94631943b4c49083825a7a
Ha7dfe9b13d174001993a6f8f38ee834fv
Hb807b299b1924daca0980b3ceca81be8s
H80bdd692443e4ee782e6c8ede49a2b62h

StarFarm Multi-Span Hot Dip Galvanized Steel Frame Greenhouse

Consulta
Productos relacionados
Si necesita productos personalizados, Póngase en contacto con nosotros !
Categoría

StarFarm Multi-Span Hot Dip Galvanized Steel Frame Greenhouse

Consulta
Productos relacionados
Si necesita productos personalizados, Póngase en contacto con nosotros !
Categoría

Descripción del producto

Productos relacionados

Invernadero agrícola acristalado con ventilación lateral y superior
Multi-Span Metal Frame Structure Agricultural Greenhouse
Invernadero de cristal agrícola de carga múltiple anti-nieve
Invernadero comercial multipanel de cristal con sistema hidropónico

Tipo: Invernaderos agrícolas de varias naves
Lugar de origen: Jiangsu, China
Fabricante: Starfarm
Material de la cubierta: Vidrio
Número de modelo: GH-MS-G-2501
Marca: Starfarm
Nombre del producto: Invernaderos agrícolas multipanel
Aplicación: Verduras, frutas, flores
Material: Estructura de acero galvanizado en caliente
Características: Estructura estable, Fácil montaje
Cubierta: Invernadero con cubierta de cristal

Large-Scale Glass Greenhouse for Vegetable and Flower Farming

Size: Large
Tipo: Invernaderos agrícolas de varias naves
Lugar de origen: Jiangsu, China
Manufacturer: StarFarm
Material de la cubierta: Vidrio
Número de modelo: GH-MS-G-2501
Brand Name: StarFarm
Application: Vegetable, Fruit, Flower, Farm
Features: Temperature Control, Recyclable, ECO-Friendly
Ventilation: Side Vents
Length: 20–100 m, Customized
Width: 6–9 m

Venlo Type Glass Greenhouse

Precio unitario: 25-95 USD/metro cuadrado

MOQ: 300 metros cuadrados

Materiales: Vidrio templado + Acero galvanizado

Tamaño: Personalizable
