Beschreibung des Produkts

Einführung

The main structure of the greenhouse is simple and practical, with low construction and operation cost. In the cold area, the top can be designed with double arches and double layer films, which can effectively prevent heat loss and the invasion of cold air, with good insulation effect and low operation cost in the winter. The surrounding coverage can choose polycarbonate sheet, glass, film (single layer, double layer).

Artikel	Einzelheiten
Struktur Typ	Multi-span Arch Film Greenhouse
Width per Span	6m / 8m / 9.6m / 10m (customized)
Länge	20–100m or more, flexible
Firsthöhe	4.5m–6.5m (depends on span width)
Frame Material	Hot-Dip Galvanized Steel Pipe
Pipe Diameter	Φ25 / Φ32 / Φ40 / Φ48 / Φ60mm
Pipe Thickness	1.5 / 1.8 / 2.0 mm/customized
Covering Material	UV-stabilized PE / PO Film
Film Thickness	120–200 microns
Lifespan of Film	3–5 years
Belüftungssystem	Manual or motorized side & roof vents
Rainwater Drainage	Internal steel gutters with downspouts
Foundation	Embedded with anchor bolts

Product Advantages

Adaptable to Different Climates with Flexible Configurations

Customizable for various climate zones with options for roof/side ventilation, shading, misting, or drip irrigation systems to maintain optimal growing conditions in tropical, temperate, or cold regions.

Newly Developed Lock Channel for Enhanced Film Stability

The newly designed integrated locking channel, made from high-strength galvanized steel with optimized angles, firmly secures the plastic covering film to prevent loosening or slippage under strong winds or temperature fluctuations.

High Light Transmittance (≥92%) for Better Crop Growth

Polyethylene film 120-200 micron film; Anti-drip, anti-mist, anti-UV ;Light transmittance>92%

Light diffusion:53%

Light: white, light blue ;Service life: 4-5years

Modular Design for Easy Transport and Assembly

All components are standardized and clearly labeled for efficient container loading and on-site assembly. The structure can be expanded or relocated easily for large-scale projects.

Greenhouse for strawberry

Greenhouse for tomatoes

Greenhouse for lettuce

Greenhouse for flower

Greenhouse for seedling

Greenhouse for hydroponic

Customizable Heavy-Duty Large Multi-Span PE Film Transparent Greenhouse

Name: Customizable Heavy-Duty Large Multi-Span PE Film Transparent Greenhouse - STARFARM
Brand: STARFARM
Price: 14.00 CNY
Availability: InStock
